Vertical Glass Lined Storage Tank

Iav lined cia tank/receiver yog ib qho zoo tagnrho rau kev cia thiab ntim cov tshuaj corrosive los yog siab purity pharmaceuticals. Vertical hom iav lined cia tank / txais tau ua ntej ntawm thaj chaw me me, tab sis muaj peev xwm me dua li hom kab rov tav, thiab yuav tsum xav txog cov cua load thiab cov kua dej zoo li qub thaum tsim.

Vertical hom iav lined cia tank / txais kuj muaj ob hom kev tsim: qhib los yog flanged qauv, tag nrho kaw los yog monoblock hom.

Vertical flanged hom iav lined cia tank / txais yog ib hom ntawm ob daim iav-lined steel hlab rau tshuaj cia. Nws muaj lub cev lub cev thiab lub hau sib cais, thiab lub hau npog txuas thiab sib khi rau lub nkoj lub cev los ntawm flange, gasket thiab nuv-shaped clamps. Nws yog ib qho yooj yim los ntxuav, tswj thiab kho los ntawm qhib lub hau.

Vertical monoblock hom iav lined cia tank / txais yog ib hom puv-kaw welded iav-lined steel hlab rau tshuaj cia. Los ntawm qhov tsis muaj qhov qhib loj loj ua kom lub taub hau siab tshaj plaws thiab tso cai rau kev ntsuas siab dua.

Kev tsim qauv ntawm iav lined cia tank / txais yog un-jacketed qauv, kuj tuaj yeem sib dhos U hom tsho lossis semi-coil hom tsho lossis sab hauv coil rau kev hloov pauv kub raws li kev cai.

STANDARD PRODUCT SPECIFICATION

MANUJFACTURE PROCESS

NTA ntawm peb cov iav LINED khoom

Corrosion Resistance - Cov iav sab hauv yog tiv taus corrosion los ntawm acids thiab alkalies (tshwj tsis yog rau hydrofluoric acid thiab kub concentrated phosphoric acid)

Anti-stick - Ntau cov ntaub ntawv yuav tsis lo rau iav, tab sis yuav lo rau hlau

Purity - Cov iav sab hauv muaj cov qauv zoo rau kev siv zaub mov thiab tshuaj

Flexibility - Cov iav kab hlau tuaj yeem ua ntau hom tshuaj lom neeg

Yooj Yim Los Ntxuav - iav hauv ob sab phlu ua kom ceev, yooj yim tu thiab kom tsis muaj menyuam

Tsis Muaj Cov nyhuv Catalytic - tshem tawm qhov ua tau ntawm cov nyhuv catalytic uas tuaj yeem tshwm sim hauv cov hlab ntsha ua nrog ntau yam kab txawv hlau.

Kev lag luam - tus nqi yog piv rau stainless hlau thiab feem ntau alloys

Rwb thaiv tsev zoo heev - Thaum twg 20KV high-frequency spark test, hluav taws xob tsis tuaj yeem nkag mus rau hauv cov iav kab

Kub Resistance - Thermal conductivity tsuas yog 1 mus rau 0.1 feem pua ​​ntawm cov hlau

Impact Resistance - Qhov cuam tshuam ntawm cov khoom zoo tshaj yog 260 * 10-3J

Customized Design - Tsim thiab tsim khoom raws li qhov xwm txheej thiab kev xav tau ntawm cov neeg siv khoom

INAPPLICATION MEDIA & CHAW UA HAUJ LWM NTAWM COV KHOOM HAUS LINED EQUIPMENT

TSEEM CEEB TSHAJ PLAWS

◆ Mechanical Performance Test rau steel substrate

◆ Tensile lub zog kuaj rau clamps

◆ Kev ntsuas kev tiv thaiv corrosion rau iav hauv ob sab phlu / enamel nrog ntsuas bar lossis thaiv

◆ Weld kev soj ntsuam nrog lub taub hau: RT-100 feem pua ​​thiab plhaub: RT-20 feem pua

◆ Nozzles txoj hauj lwm thiab kev soj ntsuam flatness

◆ Kev tshuaj xyuas qhov pom ntawm cov iav txheej tom qab tua

◆ Lined iav thickness nrhiav tau tom qab tua

◆ 20kV spark test rau cov iav txheej tom qab tua

◆ Hydraulic xeem rau Jacket thiab Vessel

◆ 10kV txim taws kuaj thiab tshuaj xyuas tiav rau cov txheej iav txheej ua ntej xa khoom

KHOOM PLIG CONSTRUCT & ACCESSORIES

Plhaub/Vessel/Jacket - Q235B(GB/T 3274-2017}) / Q245R or Q345R(GB/T 713-2014}) los ntawm cov hom nto moo

High-caj dab Flange / Manhole Flange / Nozzles - Q235B (GB / T 3274-2017) / 10 # lossis 20 # Forged steel (NB / T 47008-2017)

Clamps - 35# Forged steel (NB/T 47008-2017) nrog nto zinc-plated los yog chrome-plated

Split Backing Flange- Q245R (GB/T 713-2014) nrog nto zinc-plated los yog chrome-plated

Manhole Npog & Tiv Thaiv Ring - Q245R los yog Q345R (GB / T 713-2014) los ntawm hom nto moo

Gaskets - PTFE hnab ntawv hom gaskets nrog corrugated stainless hlau nplhaib thiab Non-Asbestos inserts (HG / T 2050-2019)

EXPORT

Peb tus khub

VISITORS THIAB EXHIBITION

FAQ

Rau peb tuaj yeem hais kom raug thiab muab cov khoom lag luam zoo, thov muab cov ntaub ntawv qhia nrog rau koj qhov kev nug xws li:

1.Yuav tsum tau tsim thiab ua haujlwm siab, kub ntawm cov khoom siv

2.Qhov kev ua haujlwm corrosion lossis PH tus nqi ntawm kev ua haujlwm nruab nrab (yog tias muaj)

3.Txuas tus qauv flange
