Qhib Hom iav Lined Reactor

Lub peev xwm ntawm qhib hom iav lined reactor yog los ntawm 50 mus rau 12500 Litres, nws yog ib hom ntawm ob-thooj ntsug hom siab lub nkoj khoom nrog rau sab saum toj ntxig agitator, tseem hu ua "Flange type" lossis "Clamped type". Kev faib cov qauv tsim tuaj yeem hloov tau yooj yim hloov lub npog sab saum toj lossis lub nkoj lub cev sib cais.

Xa kev nug

Hauj lwm lawm

Iav-lined reactor yog hom ntawm cov hlab ntsha siab uas ua ke nrog cov iav fusion nrog sab nraud steel qauv rau hauv ib lub cev, nws tiv taus kev tawm tsam los ntawm cov tshuaj feem ntau thiab cov khoom sib xyaw ntawm cov khoom siv corrosive uas yog siv rau hauv ntau yam txheej txheem tshuaj. hnyav tshuaj. Iav-lined reactors yog meticulously tsim nrog impermeable, du, anti-stick nto uas ua tiav qhov zoo tshaj plaws ntawm kev tiv thaiv corrosion, thermal zog thiab txhua yam muaj zog.

Qhib hom iav lined reactor yog ib hom ob-thooj ntsug hom khoom siv lub nkoj siab nrog agitator, tseem hu ua "Flange type" lossis "Clamped type". Nws cov qauv feem ntau suav nrog cov iav uas tshem tau sab saum toj npog uas txuas thiab sib khi rau lub iav lined hlab ntsha lub cev los ntawm flange, gasket thiab nuv-shaped clamps rau ib qho tseem ceeb kaw lub nkoj, sab saum toj ntxig iav-lined agitator, lub cev muaj zog-iav tsav tsheb, ncej. foob, U hom lossis limpet coil hom cua sov / txias tsho, iav / PTFE lined flush valve, ntsuas kub thiab siab ntsuas thiab lwm yam. Cov qauv tsim suav nrog ob lub tshuab sib txawv, ib qho yog GB Standard K Series, lwm qhov yog DIN28136 Standard AE Series. Cua sov thiab/los yog txias txoj kev yog nrog au hom tsho los yog sab nraud semi-coil tsho los ntawm nruab nrab ntawm chav dej, dej los yog thermal roj.

Kev faib cov qauv tsim ntawm qhib hom iav lined reactor tuaj yeem hloov tau yooj yim hloov lub npog sab saum toj lossis lub nkoj lub cev nyias.

Fig-1 Structure of open type glass lined reactor

PRODUCT SPECIFICATION

Muaj peev xwm	50 txog 5000 Litres (K series, GB / T25027-2018); 63 txog 6300 Litres (AE series, DIN28136); 6300 txog 12500 Litres (Customize)
Tsim Siab Lub Nkoj	{{0}}.25 Mpa, 0.6 Mpa, 1.0 Mpa
Tsim Siab ntawm Jacket	0.6 Mpa
Hom Jacket	U Hom lossis Semi-coil Hom
Tsim Kub	-20 txog 200 degree (K series) -25 txog 230 degree (AE series)
Thickness ntawm Lined iav	{{0}}.8 txog 2.0 hli (K series) 1.5-2.3 hli (AE series)
Hom Agitator (Yeem) & Ceev	Ncej / thauj tog rau nkoj hom: 50 txog 80rpm nrog cov hniav kawg linear ceev tsis ntau tshaj 5m / s; Propeller / impeller / paddle hom: 70 txog 125rpm; ua ke hom los yog raws li customized
Tsav Device rau Agitating	Flameproof AC Tsav (yeem) nrog ntsug hom Reducer
Ncej foob	Lub foob ntim khoom (tsawg dua lossis sib npaug rau 0.25 Mpa); Ib Hom Mechanical Foob (0.4 Mpa); Ob Chav Hom Mechanical Foob ({{0}}}.6 Mpa, 1.0 Mpa); Magnetic Foob (yeem)
Spark Test rau Lining-iav	20KV tom qab iav-ling raug rho tawm haujlwm, thiab 10KV ua ntej xa khoom
Kev Ntsuas Hydraulic	1.2 npaug tsim siab rau lub tsho & lub nkoj
Kub Resistance	Chilling shock: 110 degree, Thermal shock: 120 degree
Tsim qauv	GB/T150.1~4-2011,TSG21-2016/XG1-2020, GB/T25025-2010, GB/T25027-2018, HG/T{{7 }}, (K series); ASME Section Ⅷ Div. 1 Unstamped, DIN28136 (AE series); Los yog tawm tsam customized txheem
Nozzle & Flange Standard	HG/T (GB), ASME, JIS, DIN (Yeem)

MANUFACTURE txheej txheem

Fig-2 Manufacture process of glass lined reactors K type, AE typ(002)

NTA ntawm peb cov iav LINED khoom

Corrosion Resistance - Cov iav sab hauv yog tiv taus corrosion los ntawm acids thiab alkalies (tshwj tsis yog rau hydrofluoric acid thiab kub concentrated phosphoric acid)

Anti-stick - Ntau cov ntaub ntawv yuav tsis lo rau iav, tab sis yuav lo rau hlau

Purity - Cov iav sab hauv muaj cov qauv zoo rau kev siv zaub mov thiab tshuaj

Flexibility - Cov iav kab hlau tuaj yeem ua ntau hom tshuaj lom neeg

Yooj Yim Los Ntxuav - iav hauv ob sab phlu ua kom ceev, yooj yim tu thiab kom tsis muaj menyuam

Tsis Muaj Cov nyhuv Catalytic - tshem tawm qhov ua tau ntawm cov nyhuv catalytic uas tuaj yeem tshwm sim hauv cov hlab ntsha ua nrog ntau yam kab txawv hlau.

Kev lag luam - tus nqi yog piv rau stainless hlau thiab feem ntau alloys

Rwb thaiv tsev zoo heev - Thaum twg 20KV high-frequency spark test, hluav taws xob tsis tuaj yeem nkag mus rau hauv cov iav kab

Kub Resistance - Thermal conductivity tsuas yog 1 mus rau 0.1 feem pua ntawm cov hlau

Impact Resistance - Qhov cuam tshuam ntawm cov khoom zoo tshaj yog 260 * 10-3J

Customized Design - Tsim thiab tsim khoom raws li qhov xwm txheej thiab kev xav tau ntawm cov neeg siv khoom

Fig-3 FEATURES OF GLASS LINED EQUIPMENT(001)

CERTIFICATE

Peb tus khub

VISITORS THIAB EXHIBITION

PLANTESITE

EXPORTS

INAPPLICATION MEDIA & CHAW UA HAUJ LWM NTAWM COV KHOOM HAUS LINED EQUIPMENT

FAQ

1. Rau peb tuaj yeem hais kom raug thiab muab cov khoom zoo, thov muab cov ntaub ntawv qhia nrog rau koj qhov kev nug xws li:

1) Yuav tsum tsim thiab ua haujlwm siab, kub ntawm cov khoom siv

2) Kev ua haujlwm corrosion lossis PH tus nqi ntawm kev ua haujlwm nruab nrab (yog tias muaj)

3) Txuas flange txheem

4) Fais fab mov - Voltage, zaus, tawg pov thawj thiab tiv thaiv chav kawm raws li daim ntawv thov teb

5) Cov cuab yeej ua haujlwm ambient - Qhov chaw teeb tsa (Chav / sab nraum zoov teeb tsa, rhuab / unheated chav), chav kawm ntawm thaj chaw muaj kev phom sij thiab hluav taws kub, huab cua version thiab qeb ntawm qhov chaw

2. Peb MOQ yog ib txheej ntawm txhua yam khoom siv.

3. Peb qhov chaw nres nkoj yog Qingdao seaport, PRChina

4. Peb lub sijhawm xa khoom yog los ntawm 60 mus rau 120 hnub tom qab peb tau txais 30 feem pua ntawm cov nyiaj tso nyiaj thiab lees paub cov duab kos rau cov khoom sib txawv.

5. Peb cov khoom warranty lub sijhawm yog ib xyoos los ntawm kev xa khoom.

6. Peb lub sij hawm them nqi feem ntau yog 30 feem pua ntawm cov nyiaj cog lus los ntawm T / T siab tshaj li tso nyiaj, tshuav 70 feem pua ntawm T / T lossis L / C thaum pom.

7. Yog tias koj xav tau daim ntawv pov thawj qhov teeb meem los ntawm tus neeg thib peb, thov qhia rau peb paub.

Fig-16 FAQ(001)

RERRED STANDARD LIST

Yam khoom	STANDARD & REFERRED STANDARD
iav Lined Reactor	DIN 28136, UA GB/T25025-2010,GB/T25025-2017,GB/T25027-2018,HG/T20569-2013
iav Lined Agitator / Stirrer	DIN28157, DIN28158, HG/T2051.1 ~ 4-2019
Iav Lined Thermowell	DIN28147, HG/T2058.1 ~ 2-2016
Iav Lined Flush Valve	DIN28140, HG/T 3217-3218-2016
Mechanical Foob Rau iav Lined Steel Vessel	DIN28138, HG/T 2057-2017
Manhole Rau iav Lined Steel Vessel	DIN 28153, UA HG/T2055.1-2015,HG/T2055.{3}
Sight Glass Rau iav Lined Steel Vessel	DIN28121, HG/T 2144-2018
Gaskets Rau iav Lined Steel Vessel	DIN28148, HG/T 2150-2019
Loose Flange Rau iav lined Steel Vessel	DIN28150, HG/T 2105-2017
Clamps Rau iav lined Steel Vessel	DIN28152, HG/T 2054-2018
Jacket Nozzles	DIN28151, HG/T 20592-2009
Manhole Flange Rau iav Lined Khoom	DIN{0}}, HG/T2053-2018
H Flange Rau iav Lined Khoom	DIN{0}}, HG/T2049-2018
Hlau Phaj Rau Siab Vessel	DIN EN10028-2, GB/T713-2014
Vuam Specifications rau lub nkoj siab	NB/T 47015-2011
Vuam Joint hom	HG/T 20583-2020
RT Kev Tshuaj Xyuas Rau Lub Nkoj Siab	NB/T47013.2-2015/III/AB/XG1-2018
MT Inspection Rau Lub Nkoj Siab	NB/T47013.4-2015/I/XG1-2018
Thickness Inspection for Lined iav	GB/T7991 5-2014
Spark Test Rau Kab iav	GB/T7991 6-2014
Resistance Test rau Lined iav	EN 15159-2, GB/T 7988-2013, GB/T 7989-2013
Hydraulic Test Rau Lub Nkoj Siab	GB/T7994 1-2014
